LangChain vs LangGraph: 4 Key Differences and When to Use Each

our lives long before LangGraph. This is a clear indication of LangGraph closing a gap. In other words, LangGraph does things that are more complicated or not possible to do with LangChain.

In this article, we’ll go over 4 key differences between LangChain and LangGraph, and how they impact the code we write to build agentic workflows.

Let’s first mention that these are not competing tools. LangGraph is part of the LangChain ecosystem. It is kind of an extension built on top of LangChain.

1. Pipeline vs Loops

LangChain is a pipeline with a clear direction:

We chain components together but in one direction, which looks like this in code:

chain = prompt | model | parser
output = chain.invoke(input)

We can still branch, run steps in parallel, and construct DAGs, but the default abstraction is data being moved forward through a pipeline.

This structure is enough for solving many problems such as

• Retrieve documents, then generate an answer
• Extract fields, then save them
• Summarize text, then classify it

However, when it comes to sending backward, we need to write an outer Python loop. Hence, the application handles the rest, not LangChain.

On the other hand, LangGraph treats loops as part of the workflow itself. It is basically a graph with nodes and edges.

• A node performs a particular task.
• A normal edge defines fixed transitions between nodes.
• A conditional edge decides where to go next.

Thanks to the normal and conditional edges, we can route back to earlier nodes without a hustle. Here is the diagram of a customer service agent I built with LangGraph:

Customer represents the input node, AI Agent is the model, price and booking engines are the other nodes. We can go back and forth between nodes.

2. Stateless vs Stateful

A LangChain pipeline does not hold a state within itself. Each runnable usually receives an input and returns an output. State is passed forward in the form of a dictionary, message, or a custom object.

This is enough when each step needs only the previous step’s result. However, once we have a more complex workflow with loops or branches, it is on us to track the current draft, validation errors, conversation history, retry counts, etc.

We can manage all of that writing extra Python code but, as we mentioned earlier, it’s not part of the chain.

LangGraph creates stateful agents so the state is part of the graph. We declare a schema for the state, usually in the form of a TypedDict . For example, here is the state object of my customer service agent:

class AgentState(TypedDict):
    messages: Annotated[list[AnyMessage], add_messages]
    booking_details: BookingDetails
    calculated_price: NotRequired[float | None]
    time_options: NotRequired[list[TimeOption]]
    selected_slot: NotRequired[TimeOption | None]
    status: BookingStatus
    booking_id: NotRequired[str | None]

A node does not have to reconstruct the entire state. It can do partial updates and LangGraph handles it smoothly. In this agent, we have a price engine node, which only updates the calculated_price in the agent state:

def calculate_price_node(state: AgentState) -> dict[str, Any]:
    return {"calculated_price": calculate_price(state["booking_details"])}

LangGraph then merges that update into the existing state.

State fields can also have reduces for values written by multiple nodes or same node multiple times. For example, the messages field of the customer service agent state is updated after every customer message so we have a reduced (add_messages ) for this field ( messages: Annotated[list[AnyMessage], add_messages]).

Without a reducer, a new value normally replaces the old value, which is something we should avoid when keeping track of chat history.

3. Human-breaks-the-loop vs Human-in-the-loop

We’ve witnessed agents making crucial mistakes. So, especially for some critical tasks, we may want to intervene with agents operations.

Suppose an agent prepares a database migration, refund, or production deployment. We may want a human-in-the-loop to approve it before agent actually executes.

With a conventional LangChain pipeline, the common approach is to build that pause into the application surrounding the pipeline. A typical approach would be:

1. Run the chain until it proposes an action.
2. Save the proposal somewhere.
3. Return control to an API or job queue.
4. Wait for an approval event.
5. Reconstruct the required context.
6. Start the next portion of the workflow.

This approach works but requires a lot of work. It sounds more like a human-breaks-the-loop and reconstructs it.

On the other hand, LangGraph provides dynamic interrupt() calls inside nodes. Interrupts allow us to pause graph execution at specific points and wait for external input to continue.

When we trigger an interrupt, LangGraph saves the graph state so we don’t need to worry about losing information or data.

Dynamic interrupts can include a payload and resume with a human response. Here is an example:

from langgraph.types import interrupt

def approval_node(state: State):
    approved = interrupt({
        "question": "Run this migration?",
        "sql": state["sql"],
    })
    return {"approved": approved}

4. Restarts vs Resume

When a step in a normal chain fails, the simplest way to recover is often to invoke the chain again. This can be an expensive option because preceding model calls, retrieval queries, transformations, other tool calls need to be repeated.

We can add caching and write custom resume logic but those would not be part of the chain. Similar to our discussing in previous points, these are handled on the application level, not in LangChain.

LangGraph has something called checkpointer, which is a state persistence layer that saves a snapshot of an agent’s graph state at every step of execution.

In order to activate it, we just need compile the graph with a checkpointer:

graph.compile(checkpointer=checkpointer)

Checkpoints allows for resuming after a failure rather than restarting the entire workflow. This saves us the cost (both time and money) of executing the successful operations again.

We can also inspect the state before a problematic code or restart execution from any of the earlier checkpoints.

When to use which

We can stick with LangChain pipelines when the workflow is mostly predictable and forward-moving such as:

• Standard RAG pipelines,
• Simple question-answering bots,
• Document extraction and classification tasks,
• Summarization

If the control flow is complex and constitutes the major part of our agentic system, we should consider using LangGraph.

A typical use case would be coding assistants that generate, test, and repair code.

LangGraph is also a better fit for workflows with repeated planning and evaluating actions.

As we mentioned in the “restarts vs resume” section, applications that require pause, persist, and resume can advantage from the stateful LangGraph agents.

Use LangChain when your application is best understood as a pipeline. Use LangGraph when it is better understood as a stateful system.

Thank you for reading!
